consul配合swoole注册服务调用服务

1. 创建服务

2. 启动服务端 php artisan ff这里是我用到了laravel的consul

3. 获取服务数据

  业务执行流程是：利用consul注册服务-》利用swoole的客户端去连接swoole的服务端调用注册在swoole里的服务代码业务。

  注意：本片文章为记录个人demo流程，无参考价值

<?php
/**
 * Created by PhpStorm.
 * User: Administrator
 * Date: 2021/9/7
 * Time: 18:26
 * 控制器
 */

namespace App\Http\Controllers;


use App\Client\UserClient;
use App\Plug\Consul\DestroyService;
use App\Plug\Consul\GetService;
use App\Plug\Consul\RegisterService;

class ConsulController extends Controller
{

    public $ip = '172.16.0.100';

    /**
     * 获取服务
     */
    public function getOneConsulService()
    {
        $a = (new GetService($this->ip,'8510'))->getOne('order');
        dd($a->original['data']->Address);
    }

    /**
     * @return \Illuminate\Http\JsonResponse
     * @throws \GuzzleHttp\Exception\GuzzleException
     * 获取全部服务
     */
    public function getAllConsulService()
    {
        return  (new GetService($this->ip,'8510'))->getAll();
    }


    /**
     * 注册服务
     */
    public function addConsulService()
    {
        //id 服务id name 服务名称
        $mode  = new RegisterService($this->ip,'8510');
        return $mode->register('order','OrderService',['order_tag11'],$this->ip,9506);
    }

    /**
     * 删除服务
     */
    public function removeConsulService()
    {
        //id 服务id
        $mode = new DestroyService($this->ip,'8510');
        return $mode->destroy('order');
    }


    /**
     * 获取服务数据
     */
    public function getService()
    {
        $client = new UserClient();
        return $client->service('order')->getUserList(1,'DaoUserService',$this->ip);
    }
}

<?php
/**
 * Created by PhpStorm. 链接Consul
 * User: Admin
 * Date: 2021/7/29
 * Time: 22:51
 */

namespace App\Plug\Consul;

use GuzzleHttp\Client;
class GetService
{
    private $client;
    private $base_uri;
    private $port;
    public function __construct($base_uri,$port)
    {
        $client = new Client([
            'base_uri' =>$base_uri.':'.$port,
            'timeout'  =>3.0,
        ]);
        $this->client = $client;
        $this->base_uri = $base_uri;
        $this->port = $port;
    }


    /**
     * 获取指定ID的服务
     * @param $service_id
     * @return \Illuminate\Http\JsonResponse
     * @throws \GuzzleHttp\Exception\GuzzleException
     */
    public function getOne($service_id)
    {
        $response = $this->client->get('/v1/agent/service/'.$service_id);
        $reason = $response->getReasonPhrase();
        $body = $response->getBody()->getContents();
        if($reason == 'OK'){
            return response()->json([
                'code'=> 0,
                'data'=>json_decode($body)
            ]);
        }else{
            return response()->json([
                'code'=>1000,
                'message'=>"获取失败"
            ]);
        }
    }


    /**
     * 获取所有服务
     * @return \Illuminate\Http\JsonResponse
     * @throws \GuzzleHttp\Exception\GuzzleException
     */
    public function getAll()
    {
        $response = $this->client->get('/v1/agent/services');
        $reason = $response->getReasonPhrase();
        $body = $response->getBody()->getContents();
        if($reason == 'OK'){
            return response()->json([
                'code'=> 0,
                'data'=>json_decode($body)
            ]);
        }else{
            return response()->json([
                'code'=>1000,
                'message'=>"获取失败"
            ]);
        }
    }

}

<?php
/**
 * Created by PhpStorm. 向Consul内注册服务
 * User: Administrator
 * Date: 2021/7/28
 * Time: 19:04
 */

namespace App\Plug\Consul;


use GuzzleHttp\Client;

class RegisterService
{
    private $client;
    private $base_uri;
    private $port;
    public function __construct($base_uri,$port)
    {
        $client = new Client([
            'base_uri' =>$base_uri.':'.$port,
            'timeout'  =>3.0,
        ]);
        $this->client = $client;
        $this->base_uri = $base_uri;
        $this->port = $port;
    }


    /**
     * @param $id 服务id
     * @param $name 服务名称
     * @param array $tags 服务标签
     * @param $port服务端口
     * @return \Illuminate\Http\JsonResponse
     * @throws \GuzzleHttp\Exception\GuzzleException
     */
    public function register($id,$name,$tags=[],$ip,$port)
    {
        $data = array(
            "ID"=>$id,
            "Name"=>$name,
            "Tags"=>$tags,
            "Address"=>'127.0.0.1',
            "Port"=>$port,
            "Check"=>array("HTTP"=>"http://".$this->base_uri.':'.$this->port,"Interval"=>"5s")
        );
        $response = $this->client->put('/v1/agent/service/register', [
            'headers' => ['Content-Type' => 'application/json'],
            'json'=>$data
        ]);
        $body = $response->getBody()->getContents();
        if(!$body){
            return response()->json([
                'code'=> 0,
                'message'=>"注册成功"
            ]);
        }else{
            return response()->json([
                'code'=>1000,
                'message'=>"注册失败"
            ]);
        }
    }


}

<?php
/**
 * Created by PhpStorm. swoole 服务层
 * User: Admin
 * Date: 2021/7/29
 * Time: 23:20
 */

namespace App\Service;


use App\Plug\Consul\RegisterService;
use App\Service\Dao\DaoUserService;


class UserServer
{
    protected $server;
    protected $class;

    public function __construct()
    {
        $this->server = new \Swoole\Server("0.0.0.0", 9506);
        $this->onConnect();
        $this->onReceive();
        $this->onClose();
        $this->onWorkerStart();
        $this->onStart();
        $this->start();
        $this->server->set(array(
            'open_length_check'     => true,    // 开启协议解析
            'package_max_length'    => 81920,
            'package_length_type'   => 'N',  // 长度字段的类型
            'package_length_offset' => 0,   //从第几个字节是包长度的值
            'package_body_offset'   => 4,   //从第几个字节开始计算长度
        ));
    }

    public function onStart()
    {
        $this->server->on('start', function ($serv) {
            //注册服务
            //$res = (new RegisterService('192.168.211.130','8510'))->register('user','UserServer',['user_tag'],9504);
            //echo 'consul注册成功'.$res.PHP_EOL;
        });
    }

    public function onWorkerStart()
    {
        $this->server->on('WorkerStart', function ($serv, $fd) {
            $this->class = new DaoUserService();
            echo "OrderServer: 启动.\n";
        });
    }

    public function onConnect()
    {
        $this->server->on('Connect', function ($serv, $fd) {
            echo "Client: Connect.\n";
        });
    }

    public function onReceive()
    {
        $this->server->on('Receive', function ($serv, $fd, $from_id, $data) {

            $info = unpack('N', $data);
            $len = $info[1];
            $body = substr($data, - $len);
            $data = json_decode($body, true);

            $service = $data['service'];
            $action = $data['action'];
            $page = $data['param'];
            $class = $data['class'];
            //$instance = new $class;
            $instance =  $this->class;
            $result = $instance->$action($page);
            $result = json_encode($result);
            $serv->send($fd, $result);
        });
    }

    public function onClose()
    {
        $this->server->on('Close', function ($serv, $fd) {
            echo "Client: Close.\n";
        });
    }

    public function start()
    {
        $this->server->start();
    }
}

//new  UserServer();
